Sunsynk Wall Mount Battery LiFePO4 5.32 KWh SUN-BATT-5.32
Sunsynk’s top-grade 5.32kWh Lithium-Ion Phosphate batteries have been engineered to the highest standard.
They are capable of up to 80% depth of discharge and scalable up to 16 times, allowing for a maximum of 85.12kWh per inverter.
Our BMS (Battery Management System) also offers a quick paralleling function, so no dip switches are needed, making installation straightforward.
Sunsynk Wall Mount Battery LiFePO4 5.32 KWh SUN-BATT-5.32 is 1C rated, meaning that it will be able to charge or discharge at the full 5.32kWh until it is depleted. This allows the end user to utilise the full potential of our inverter and battery systems.
Sunsynk Wall Mount Battery LiFePO4 5.32 KWh SUN-BATT-5.32 Performance
- Nominal Voltage: 51.2 Vdc
- Nominal Capacity: 104Ah
- Battery Energy1: 5320 Wh
- Charge Voltage: 55.68~56.16Vdc
- Discharge Voltage: 45.6-56.16 Vdc
- Nominal Charge/Discharge Current: 50A
- Nominal Charge/Discharge Power: 2500W
- Max Charge / Discharge Current: 100A
- Max Charge / Discharge Power: 5000W
- Short Circuit Current: 350A
- Display: SOC status indicator, LED indicator
- Communication: RS232, RS485, CAN
- Dimension (W×D×H mm) 450x520x185mm
- Weight: 46.5kg
- Installation: Floor stand or Wall mounted
- Working Temperature2 -20ºC ~ 60ºC
- Storage Temperature:
≤25ºC, 12 months
≤35ºC, 6 months
≤45ºC, 3 months - Operating / Storage / humidity: ≤ 95%RH
- Max Operating Altitude: ≤2000m
- IP Rating: IP20
- Cell Technology: LiFePO4, Lithium-iron Phosphate
- Cycle life: 6000 Cycles @ 80% DOD / 25ºC / 0.5C, 60% EOL
- Scalability: Max 8 batteries in parallel
- Certification: PACK:UN38.3, IEC62619, IEC61000, CELL:UN38.3,
IEC62619, UL 1642, JET (more available upon request)
Shop our Solar Range HERE
